DISPLAY NAVIGATION
Output Analog Menu
Scroll through with Up and Down buttons, press Menu button to apply your changes *---wait---* will display as changes are applied.
OUTPUT

OUTPUT
AUX BINARY

See Output Aux Binary Menu (previous page)

OUTPUT
ANALOGS

AUX. COOL MIN
0.0 VDC
Auxiliary Cool Min Voltage
· Outputs this voltage on Auxiliary Analog pin when there is a minimum call for cooling.
· Default: 0.0 VDC.

AUX. COOL MAX
10.0 VDC
Auxiliary Cool Max Voltage
· Outputs this voltage on Auxiliary Analog pin when there is a maximum call for cooling.
· Default: 10.0 VDC.

AUX. HEAT MIN
0.0 VDC
Auxiliary Heat min Voltage
· Outputs this voltage on Auxiliary Analog pin when there is a minimum call for heating.
· Default: 0.0 VDC.

AUX HEAT MAX
10.0 VDC
Auxiliary Heat Max Voltage
· Outputs this voltage on Auxiliary Analog pin when there is a maximum call for heating.
· Default: 10.0 VDC.

AUX DEADBAND
0.0 VDC
Auxiliary Idle Voltage
· Outputs this voltage on Auxiliary Analog pin when there is no call for heating or cooling
(deadband).
· Default: 0.0 VDC.

AUX. UNOCC.
0.0 VDC
Auxiliary unoccupied voltage
· Outputs this voltage when Auxiliary Analog pin is set to unoccupied.

