5.4.6 Zoom Button
The zoom function can be used to more accurately view the peak position. Tapping the zoom button
will display zoom in + and zoom out – buttons at the bottom left of the display; the zoom button will
show in yellow to indicate zoom mode is active.
Tap the + or – button to zoom in or out as required. The zoom will be active around the current cursor
position, so the Goto Peak button should be used before the zoom function.
A grey area will be shown on the pipe model to indicate the area of the correlation function currently
on screen.
To turn zoom off and return the correlation function to the full display, tap the yellow zoom button. The
display will return to un-zoomed mode, the zoom in and out buttons will disappear and the zoom
button will return to the blue off indication.
5.4.7 Pipe Entry Button
Tap this button to open the Pipe Details screen to enter or edit pipe details.
5.4.8 Transmitter Icon
This is a representation of the red transmitter at the end of the pipe network. Tap the Transmitter Icon
to bring up the Transmitter Menu. Each transmitter has its own menu and the options (except swap
transmitters) only affect that transmitter.
