9. Take the loose label stock and feed it between the Liner Idler Roller and the Liner Drive Roller.
(Figure 2-7.) In order to feed the label stock between the rollers, the Liner Idler Roller
should be in the unclamped position. For some thicker label stock, it may be necessary to
remove the labels from the liner before performing this step. (See Figure 2-10 for a detailed
diagram of the Liner Idler Roller positions.)
Note: This procedure assumes that the first 12 inches of labels will not be applied to the
container using the Label Applicator. Of course, you may still apply these labels by hand.
10. Pull the stock all the way through until the end of the roll is laying over the top of the label
stock roll. Adjust the label stock forward or backward so that the Peel Edge is between two
labels. (Figure 2-8.)
AP360/362 Label Applicator 7
Figure 2-8.
Figure 2-7.
Tip! There must be no
labels wrapped around
the Peel Edge.
