Printing from a PC 29
E. Creating a Full Bleed Print
1. Adjust these settings in the status monitor and printing application (BarTender).
Page Size. Increase the page size width by .03 inches (1mm). Increase the height by .03
inches (1mm). If you are using BarTender, simply change the size under the File Menu
- Page Setup. If you are using other graphics programs you will need to change the
page size in the application and in the printer driver preferences.
Left Margin Offset. You must increase the left margin offset to center the over bleed
on the label. If you over bleed by .03" you will need to increase the Left Margin Offset
by 4. This will center the page size increase so there is a .03 inch over bleed on both left
and right sides. Some additional adjustment may be necessary if the label was not
perfectly aligned to begin with. See Section 4D.
TOF. Decrease the Top of form by 4. This will cause the printer to start printing before
the label and ensure a fully printed label. Some additional adjustment may be
necessary if the label was not perfectly aligned to begin with. See Section 4D.
Note:
It is best to over bleed as little as possible to avoid excess ink on the label backing. Also, over bleeding
too much will cause the printer to skip labels. This is because the printer stops printing too late to
sense the next label.
You may have to make several adjustments to one or more of
these values. After each adjustment you can click the Test
button to print a small test pattern on the label. This will help
you find the proper alignment value.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Primera LX2000e and is the answer not in the manual?

Primera LX2000e Specifications

General IconGeneral
Display-
Color displayYes
Product colorBlack
Printing colorsBlack, Cyan, Magenta, Yellow
Print technologyThermal inkjet
Maximum resolution- DPI
Maximum print height- mm
Minimum print length12.7 mm
Maximum printing width210 mm
Core diameter76.2 mm
Maximum label width209.6 mm
Maximum label length0.6 m
Maximum roll diameter152.4 mm
LED indicatorsLow ink, Power
Mac operating systems supportedMac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB 2.0 ports quantity1
Connectivity technologyWired & Wireless
Input current1.7 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
CertificationUL, UL-C, CE, FCC Class A
Weight and Dimensions IconWeight and Dimensions
Depth521 mm
Width495 mm
Height259 mm
Weight20400 g
