Technical Specifications 45
Supply roll diameter: Up to 152mm (6”)
Media liner width: 38.1mm to 212.7mm (1.50” to 8.38”)
Label height/length: 19.1mm to 609.6mm (0.75” to 24.00”)
Supply roll core: 76.2mm (3” ID)
Print width: 19.1mm to 209.6mm (0.75” to 8.25”)
Electrical rating: 12 VDC, 5.0 A
Power requirements: 100-240VAC, 50/60 Hz, 1.7A
Speed: 6 in/sec. in Draft Mode
Agency certifications: UL, UL-C, CE, FCC Class A
Weight: 20.4 kg
Dimensions: 495mm W x 259mm H x 521mm D
Connectivity: Hi-Speed USB 2.0; Built-in wired
Ethernet 10/100 Base-TX
(RJ45) networking; Built-in wireless
802.11b/g/n networking
Section 6: Technical Specifications
