3.LifttheCartridgeCarriageLatchintothestowposition.Inthestowpositionthecartridgecarriage
latchisjustbehindthebackedgeofthecartridgeasshownbelow.Youwillseethecartridgemove
forwardslightlywhenthelatchisinthecorrectposition.
Page|13


4.Graspthecartridgecarriagelatch,w hileinthestowposition,andturnthecarriagetotheside.The
carriagelatchwillfitintothecorrespondingnotchinthebaseoftheprinter.


Note:Thestowpositionistheonlypositionwhere
thecarriageisallowedtoturneasily.Ifthecarriage
doesnotturneaslilyitisnot
intherightposition.
Notch
