FAILURE 41: SERVICE DUE WARNING
Failure 41 occurs when the cycle counter of the Electronic timer has reached the Programmed Value for
Service due. The fault message will be erased by opening the door. If the cycle counter has not been reset
the message will appear again at the end of the next wash cycle.
DIAGNOSE:
1. Check the cycle counter. The value can be found
by pressing the SERVICE-STATE button. The
second menu item shows the cycle counter.
You can reset the cycle counter in the Service
Menu.
FAILURE 42: NO NETWORK CONNECTION
Failure 42 occurs when there is No Network Connection available.
For more information about the Networking see „Manual PC-Networking“.
DIAGNOSE:
1. Check the network cable. If the network cable is broken, replace the
network cable.
2. Check the RS232-RS485 converter If the converter is out of order, replace it.
FAILURE 43: WRONG VOLTAGE RANGE SELECTION
Failure 43 occurs when the wrong Voltage Range has been selected in the Configuration menu.
Depending on the machine type and the inverter type, certain Voltage ranges are not allowed.
DIAGNOSE:
1. Check the Machine Identification plate at the
back of the machine.
Select the same Voltage range in the
Configuration menu as on the Identification
plate of your washing machine.
Menu Item C:Supply Voltage
FAILURE 44: WRONG INVERTER MODEL TYPE
Failure 44 occurs when the wrong Inverter Model Type has been detected by the MCB 40 software.
Before loading the parameters from the Wash Computer to the Mitsubishi inverter, the inverter type is
checked first.
DIAGNOSE:
1. Check if you have selected the correct machine
type.
Select the correct machine type in the
Configuration menu.
Menu Item C:Machine Type
2. Check the Machine Identification plate at the
back of the machine.
Select the same Voltage range in the
Configuration menu as on the Identification
plate of your washing machine.
Menu Item C:Supply Voltage
FAILURE 45: NO SPEED SENSOR SIGNAL
F120 machine only. Failure 45 occurs when the speed sensor is not sending pulses to the Wash Computer
while the drum turns.
The machine is still operational when the speed sensor is out of order. But as the machine operation is
deteriorated an intervention of a technician is required.
DIAGNOSE:
1. Check if the head of the speed sensor is
mounted at a correct distance from the reference
Check the installation and maintenance manual
how to mount the speed sensor at a correct
