100962 G PUBLICATION DATE 24 JUN 2008.DOC PROGRAMMING MANUAL 31
ATTENTION !!!
The Selection TTL is only for Mitsubishi inverters Type :
FR-A024-S0.4K - S2.2K-EC and FR-A044-0.4K - 3.7K-EC
£
For these inverters you don’t have to select the Supply
Voltage of the washing machine.
£
You have to select the list element TTL.
From October 2000, these inverters have been replaced by
inverters from the E500 Series (Current ) that do NOT function
with TTL communication anymore.
Loading the Mitsubishi Frequency Inverter Parameters is an
advanced feature.
• These parameters ensure that the Inverter – Motor
combination will function properly on your washing
machine.
• Therefore you have to make sure that the Machine Type and
Voltage Supply corresponds with the data plate at the
backside of the machine.
• Confirm by pressing the ENTER button.
• As a result you will be asked if you are sure about your
selection. C: Delete old settings ? No
• Press the Yes and ENTER button to confirm once more.
• A washing machine can be delivered with 2 or 3 water inlet supplies.
• A machine with 2 water inlet supplies functions with:
- soft warm water
- soft cold water
• A machine with 3 water inlet supplies functions with:
- soft warm water
- soft cold water
- hard or recycled cold water
• Depending this selection other inlet valves will be suggested
at the final rinse sequence.
• Depending this selection other inlet valves will be
programmed when the standard programs are loaded.
• The number of inlets must be selected by the ARROW LEFT
or RIGHT button.
• Confirm by pressing the ENTER button.
3 x 380
415 V + N | 1 x 220 – 240 V | 3 x 220 – 240 V | 3 x 380 – 480 V (N) |
1 x 208 – 240 V | 3 x 208 – 240 V | TTL
C:Total N° of
Inlets: 2
C:Load Inverter
Parameters? Yes
2 | 3
To Next Page
