8.4. OVERVIEW
N° Failure message Failure Action Fault occurrence
E1
No Drain Co
Drain failure
Cooldown
Full Stop + tumble Draining sequence Cooldown
E2
No Drain
Drain failure Full Stop + tumble Draining sequence
E3
Tilt Fault
Out of balance :
Before spin
Full stop + tumble Start spin
E4
Imbalance
Out of balance :
Normal spin
Skip + continue After 10 x tilt
E5
Tilt High Sp
Out of balance : high
spin
Full stop + safety time >500 or 750 RPM
E6
Door Coil
Door switch failure Full stop + safety time Whole cycle
E7
Door Switch
Door solenoid switch
failure
Full stop + safety time Whole cycle
E8
Door Start
Door lock check at
start failure
Don’t start At start up
E9
Door Unload
Door lock switch
closed failure
Don’t start End cycle
E10
Bimetal/Spring
Bimetal/Spring Continue 2 min 30 sec after start cycle
E11
No Fill
Fill failure
Full stop + request for
Continue
While filling
E12
Overfill
Overfill failure Full stop + tumble While filling
E13
No Heating
Heating failure Full stop + tumble While heating
E14
Heat Time
Heating time failure
Full stop + request for
Continue
While heating
E15
Too Hot
Too Hot Full stop + tumble While heating
E16
/
E17
/
E18
Thermic
TH overcurrent
security
Full stop + safety time Motor contactor ON
E19
M1 Security
M1 wash + low spin
motor security
Full stop + safety time Motor contactor ON
E20
M2 Security
M2 distribution + high
spin motor security
Full stop + safety time Motor contactor ON
E21
Overflow
Overflow failure Full stop + tumble Wash step
E22
Flush fault
Flush failure Full stop + tumble Flush step
E23
PCB temp
Defective PCB
temperature sensor
Continue Any time
E24
Level Sens
Defective level sensor Continue + Don’t start Before start up
E25
Temp Sensor
Defective temperature
sensor
Continue + Don’t start Before start up
E26
Mitsub code
Undefined frequency
inverter error code
Full stop + tumble Whole cycle
E27
Comm fault
Communication fault
inverter
Full stop + safety time Whole cycle
E28
THT time
THT Time out Full stop + safety time At spin sequence
E29
OV3 time
OV3 Time out Full stop + safety time At spin sequence
E30
Mits Alarm
Alarm frequency inverter Full stop + safety time Whole cycle
E31
Load Parr
Initialisation fault
inverter
Don’t start At initialisation
E32
Verify Parr
Verification fault
inverter
Don’t start At loading parameters
E33
Stall prev
Stall prevention
function active
Continue At spin sequence
E34
/
E35 Wrong Softw WRONG SOFTWARE
VERSION
Don’t start New software version
