7. PRE-PROGRAMMED PROGRAMS
The Full Control Wash Computer contains 15 pre-programmed Standard Wash Programs.
(Standard Programs : 1 to 15. Programs 16 to 52 are dedicated.)
ATTENTION
!!!
THE PRE-PROGRAMMED PROCESSES ARE GIVEN AS AN EXAMPLE ONLY.
FOR THE CREATION OF YOUR OWN WASH PROGRAM’S, CONTACT YOUR SOAP SUPPLIER.
7.1. LEGEND
T SUPPLY TIMES
The water supply time for hopper A, B, C, D and E is default 30 seconds and can be adjusted in the
Program menu.
T WATER INLETS (VALVES)
• Machines with TOP SOAP HOPPER
- Inlet Valve 1 : Cold Hard Water (*) Soap Hopper “C” Final Rinse
- Inlet Valve 2 : Cold Soft Water Soap Hopper „A“ Pre wash
- Inlet Valve 3 : Hot Soft Water Direct Inlet (Liquid)
- Inlet Valve 4 : Hot Soft Water Soap Hopper „B“ Main Wash
- Inlet Valve 5 : Cold Soft Water Soap Hopper „B“ Main Wash
- Inlet Valve 6 : Cold Soft Water Direct Inlet (Liquid)
(*) If No Cold Hard water is available, then Inlet Valve 1 will function with Cold Soft Water.
• Machines with FRONT SOAP HOPPER
- Inlet Valve 1 : Cold Hard water (Inlet Valve 1 is not operational, if no hard water is available)
- Inlet Valve 2 : Cold Soft water
- Inlet Valve 3 : Hot Soft water
T WATER LEVEL
- NL: Normal Low level
- NH: Normal High level
T WASH ACTION
• Normal Wash Action • Gentle Wash Action
- A = 12“ 12 Seconds Action - A = 3“ 3 Seconds Action
- R = 3“ 3 Seconds Rest - R = 12“ 12 Seconds Rest
T RPM (REVOLUTIONS PER MINUTE)
- W : type R/F/X = Washing Speed (≈ 40 – 42 RPM)
type RF/FF/XF/MB = Washing Speed (≈ 32 – 50 RPM)
- D : type R = Washing Speed (≈ 40 – 42 RPM)
type F/X = Distribution Speed (≈ 100 RPM)
type RF/FF/XF/MB = Distribution Speed (not changeable) (≈ 100 RPM)
- L : type R = Extraction speed (≈ 500 RPM)
type F/X = Low extraction speed (≈ 500 RPM)
type RF/FF/XF/MB Low extraction speed, standard (≈ 500 RPM)
- H : type R/RF = Extraction speed (≈ 500 RPM)
type F/X = 1 Minute Low (≈ 500 RPM)
+ rest high extraction speed (≈ 850 – 1000 RPM)
type FF/XF/MB = High extraction speed (≈ 625 – 1000 RPM)
(depending the size of the machine)
!
