5.5. STEP ~ : PROGRAMMING THE WASH PART
This paragraph gives a detailed explanation about programming the Wash Sequences.
 Each program step contains a wash part and a drain part.
 First the wash part must be selected, item by item can be programmed.
 Next the drain part must be selected, item by item can be programmed. See step  °.
 Without making changes you can watch item by item, by pressing the ARROW DOWN or UP
button.
 If you want to make changes :
- Insert a new value.
- Enable or disable a Setting by pressing the YES or NO button.
- Select a list element by pressing the ARROW LEFT or RIGHT button.
£ You have always to confirm by pressing the ENTER button.
 Each time you add or insert a new step, default values have been pre-programmed.
So with less effort, complete programs can be programmed.
See also chapter 3 for a general explanation concerning the creation of wash programs.
 You can recognize a list element by the LEFT and RIGHT ARROW symbol at the right side
on the display.
 The arrow down symbol on the display points to the last Menu Item : EXIT.
T SELECTING THE WASH PART
• If you have selected Add Step, Edit Step or Insert Step, you
have to select the wished wash sequence now.
• Depending the machine type with top or front soap hopper,
you have more or less sequences available.
For Washing Machines with a Soap Box at the Top :
For Washing Machines with a Soap Hopper at the Front :
• For a new step, as a default, the first displayed function is the Wash sequence.
• Now by pressing the ARROW LEFT or RIGHT button, you can select the wished sequence.
• Press the ENTER button to confirm.
• You can also use the ARROW DOWN button if you accept the pre-programmed default value.
Prewash
|
Wash
|
Cooldown
|
Rinse
|
Final Rinse
|
Soak
|
Flush
|
S
p
ra
y
|
No wash
Wash
|
Cooldown
|
Rinse
|
Soak
|
S
p
ra
y
|
No wash
P:Pr XX Step XX
Wash
