48 PROGRAMMING MANUAL 100962 G PUBLICATION DATE 24 JUN 2008.DOC
T THE WASH SEQUENCE
°C : degrees Celsius
°F : degrees Fahrenheit
• The temperature can be programmed between 1°C and 92°C.
• 60°C is the suggested default value.
• Insert the desired temperature. Press the ENTER button for
confirmation.
Top Soap-Hopper washing machines
• 4 Inlets can be programmed. I1, I2, I3, I4, I5 and I6 are
available.
• For a default value of 60°C, the suggested inlet valves are
I3, I4 and I5.
• The suggested inlet valves are related to the temperature
and the soap box.
• Insert the desired inlet valves. Press the ENTER button for
confirmation.
Front Soap-Hopper washing machines
• 3 Inlets can be programmed. I1, I2, and I3 are available.
• For a default value of 60°C, the suggested inlet valves are
I2 and I3.
• Insert the desired inlet valves. Press the ENTER button for
confirmation.
Attention
!
If you insert other inlet valves than the suggested ones,
problems can occur at the water fill process.
• The suggested Water Level corresponds with the Normal
Low water level.
• The suggested water level depends on the machine type.
• Check the corresponding table paragraph 3.4.
• The water level can only be programmed within certain limits.
• Insert the wished water level. Press the ENTER button for
confirmation.
• The suggested drum speed value depends on the machine type.
• Check the corresponding table paragraph 3.4.
• The drum speed value can only be programmed within
certain limits.
Prewash
Wash
Cooldown
Rinse
Last Rinse
Soak
Flush
S
ra
No wash
P:Pr XX Step XX
Temp : 60 °C
P:Pr XX Step XX
Inlet : _ _ _ _
P:Pr XX Step XX
Level : _ _
P:Pr XX Step XX
RPM : _ _
!
To Next Page
