Chapter 2 Install Basic Components
38
Install Basic Components
The following procedures describe how to attach the printed
overlays to the control panel and install the printer ribbon and
paper.
Attach The Control Panel Overlays
1. Choose the overlay labels in the appropriate language.
2. Cabinet Models: Open the printer cover, peel off the protective
backing off the overlay, and press the overlay into place.
3. Pedestal Models: Open the printer cover and insert overlay
labels by sliding them behind the control panel assembly in the
appropriate place.
Figure 7. Attaching Control Panel Overlays
(Left: Pedestal Models; Right: Cabinet Models)
