Characteristics
22
Characteristics
Slim Panel Characteristics
The characteristics are shown below:
Display Characteristics
DC Power Supply
The following table describes the DC power supply:
Element Characteristics
Intel chipset and
processor
Atom
™
E3827, 1.75 GHz
Expansion slot 1 x mini PCIe
Memory 4 GB, DDR3 1600 MHz, SO-DIMM SDRAM
Storage memory 1 x CFast slot
Watch dog timer 255 level timer interval, programmable 1...255 sec/min (setting through API)
Buzzer Yes
Cooling method Passive heat sink
Weight W10” Multi-touch Industrial Personal Computer: Approximately 2.5 kg (5.51 lbs)
W15” Multi-touch Industrial Personal Computer: Approximately 3.9 kg (8.6 lbs)
Element 10” Screen size 15" Screen size
Display type TFT LED LCD
Display size 10.17” 15.64”
Display resolution WXGA 1280 x 800 pixel HD FWXGA 1366 x 768 pixel
Number of colors 267,000 16.7 million
Brightness control Step less adjustment
Backlight life Life span > 50,000 h at 25 °C (77 °F)
Touch screen resolution 4096 x 4096 pixel
Multi-touch 5 simultaneous touch (projected capacitive)
Anti-scratch surface 7 H hardness
Element Characteristics
Rated voltage 24 Vdc ±20 % (the fuse becomes an open circuit if the input level exceeds
32 Vdc)
Current consumption W10” Multi-touch Industrial Personal Computer: 1.9 A typical
W15” Multi-touch Industrial Personal Computer: 1.7 A typical
