PS5000 Series (Slim Panel Type Atom Model) User Manual
141
Connectors and Setting
Main Board Setting
Before to access the main board, shut down Windows in an orderly fashion and remove all power
from the device.
NOTE: Be sure to remove all power before attempting this procedure.
The table describes how to access the main board:
DANGER
POTENTIAL FOR EXPLOSION IN HAZARDOUS LOCATION
Do not use this product in hazardous locations.
Failure to follow these instructions will result in death or serious injury.
NOTICE
ELECTROSTATIC DISCHARGE
Take the necessary protective measures against electrostatic discharge before attempting to
remove the Industrial Personal Computer cover.
Failure to follow these instructions can result in equipment damage.
Step Action
1 Disconnect the power cord to the Slim Panel.
2 Touch the housing or ground connection (not the power supply) to discharge any electrostatic
charge from your body.
3 Remove the four screws of the rear cover:
