Pro-face SP-5B10 - Removal Procedure

25
Installation
English
Removal Procedure
Removing from Display Module / DC Power Supply
Adapter for Box Module
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
• Remove all power from the device before removing any covers or elements of
the system, and prior to installing or removing any accessories, hardware, or
cables.
• Unplug the power cable from the Display Module or DC Power Supply Adapter
for Box Module, and the power supply.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace and secure all covers or elements of the system before applying
power to the Display Module or DC Power Supply Adapter for Box Module.
Failure to follow these instructions will result in death or serious injury.
NOTICE
EQUIPMENT DAMAGE
When this product is mounted vertically, from the panel first remove the
Display Module or DC Power Supply Adapter for Box Module, then remove the
Box Module from the Display Module or DC Power Supply Adapter for Box
Module.
Failure to follow these instructions can result in equipment damage.
Step Action
1 When mounting this product vertically, remove the Display Module
or DC Power Supply Adapter for Box Module from the panel, and
place the Display Module or DC Power Supply Adapter for Box
Module on a clean and level surface with the screen facing down.
NOTE : Refer to the SP5000 Series Hardware Manual or the SP5000 Series
(Display Module) Installation Guide on how to remove the Display Module
from the panel. Refer to the DC Power Supply Adapter for Box Module
Installation Guide on how to remove the DC Power Supply Adapter for Box
Module from the panel.
