Pro-Form 290 CSR User Manual

10
9
9. Attach the Seat (9) to the Seat Carriage (3) with
four M6 x 38mm Patch Screws (81) and four
M6 Washers (44) (only two of each are shown).
N
ote: The Patch Screws and Washers may
be preattached to the underside of the Seat.
9
44
81
44
3
10. Plug the Game/Pulse Wire (58) into the
Game/Pulse Receptacle (79) located in the Left
Shield (26).
10
58
26
79

Pro-Form 290 CSR Specifications

General

Brand	Pro-Form
Model	290 CSR
Category	Exercise Bike
Language	English
