Pro-Form 440R - Page 9

9
5. Move the Seat (28) to the front of the Rail (8).
Have a second person raise the Rail (8) to the
vertical position. Fully insert the Frame Pin (37)
into the indicated hole in the Rail Bracket (41) so
that it holds the Rail in place.
8
5
3
6. Attach the Rear Stabilizer (3) to the Rail (8)
with two M8 x 20mm Screws (14) and two M8 x
20mm Washers (16).
6
28
14
16
37
8
41
Hole
