12
12
16
26
18
19
17
12. Identify the Right Pedal (16). Using your fingers,
turn the Right Pedal clockwise about halfway into
the Right Crank Arm (18). Then, use the included
Pedal Wrench (26) to FIRMLY TIGHTEN the
Right Pedal.
Attach the Left Pedal (17) to the Left
Crank Arm (19) in the same way.
IMPORTANT: You must turn the Left Pedal
COUNTERCLOCKWISE to attach it.
14. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly, that it
functions properly, and that all parts are properly tightened. Extra parts may be included. Place a mat
under the exercise bike to protect the floor or carpet.
13
12
83
92
11
13. Identify the Right Weight Rest (92). Attach the
Right Weight Rest to the Frame (1) with two
M5 x 8mm Screws (83).
Attach the Left Weight Rest (12) in the same
way.
Then, set the Hand Weights (11) in the Weight
Rests (12, 92).
11
