Pro Spot PR-8 - C3. Mode 6 & Auto Program Controls

- 8 -
Pro Spot PR-8
GB/US/2000-08
PRO SPOT
C. Function selection
C3. Control pushbuttons in Mode 6, Automatic Program
Don’t forget to connect the welding cables and control cable. When using tongs, connect the
air hose on the welding cable to the air supply connection on the front panel.
Push S to select operating mode.
Push + Plus to select program.
Push – Minus to select program.
Push V to reset alarm signals.
”
+ ”
”
- ”
” v ”
”
s ”
Air
Main On/Off switch
Pressure Regulator
Welding cables
Cooling air
Trigger connection
& measurement
Pressure gauge
