Pro Spot SP-5 - Welder Unit Controls and Connections; Control Panel Interface; Electrical and Torch Connections

1
15
14
12
10
13
11
8
5
4
3
9
6
2
7
UNIT CONTROLS
1 Mode Key
2
Display
3 Setup Key
4 Prog save & recall Key
5 Right Regulation Knob
6 Material Key
7 Left Regulation Knob
8 ON/OFF Switch
9 Negative Socket
10 Postitive Socket
11 Euro Connection for Torch 1 - AL
12 Euro Connection for Torch 2 - FE/SS
13 Euro Connection for Torch 3 - CuSi and Torch TIG
14 Accessories Compartment
15 Torches Holding Bar
FIG. 6
9
