ProArc PT-200s - Technical Specifications Overview

1
1.1 SPECIFICATION
MODEL
Unit
PT- 200s
Power Input
~
1 Phase 220V 50/60Hz
Capacity (Horizontal / Vertical )(W) kg 200 / 130
Rated center of gravity(S) mm 25
Rotation speed rpm 0.01 ~ 30
Tilt range deg. 0 ~ 120
Earthing
amp
300
Overall length (A) mm 530
Overall width (B) mm 315
Overall height (C) mm 690
Center to floor (D)
mm 600
Table diameter (E)
mm
320
Spindle thru hole mm 22
Table slot bolt size M10
Weight Kg 45
