MT-1/WT3 User Guide
Page • 27
Test Examples
In the following examples, we assume the MT-1/WT3 socket is already installed into
the meter base and the meter under test is also plugged into the MT-1/WT3 socket
and the installation is well-secured. For more detailed information, please refer to
the Probewell Connect for WT Series documentation.
Below are some testing examples included in this manual. The tests are available for
all meter types :
1. Quick-Test – 9S solid-state meter
2. Custom Test – 9S solid-state meter
3. Tracking Test – 12S(N) electromechanical meter
4. Custom Test – 2S electromechanical meter
5. KW demand test – 14S (M-90) electromechanical meter
6. Full Test – 8S Fitzall™ meter
7. Four-Quadrant (WH) Test – 9S solid-state meter
8. Meter tested in a meter shop
Please download the Probewell Connect app to control and take advantage of the
meter tester’s wireless functionalities.
For more information on how to launch and run the application, refer to the
Probewell Connect WT Series User Guide available on Probewell’s website.
In the following examples, we assume that the MT-1/WT3 socket is already installed
into the meter base and the meter under test is also plugged into the MT-1/WT3
socket and the installation is well-secured.
