To install a new tire, follow these instructions:
When installing a new tire you should first insert the tube into the tire. The tube should have been partially inflated to
a soft but full feel removing any wrinkles in the tube.
Check the mounting side of the rim and confirm the directional path of the tire. High performance tires are usually
directional tires and the arrow on the sidewall represents the rotation of the tire.
Place the valve of the tube into the valve hole of the rim and slide the bead of the tire over the edge of the rim.
Push the one side wall and bead of the tire around the edge of the wheel’s rim. The tire will slide into place and may
become tight as you finish.
Once one side of the tire is inserted in the rim, check to make sure the valve stem lines up properly and the tube is
smooth across the rim and inside of tire. The tube should not be bunched up in any area.
Where the tube valve is, slide the second wall and bead of the tire into the edge of time rim. Follow pushing the tire
wall and bead into the inside edge of the rim.
You will get to an area of only a few inches left and you will need to apply pressure to push the tire side wall and
bead behind the edge of the rim.
Once the tire is fully inserted, check for any areas on both sides if the tube is exposed. The tube must not get
trapped between the tire bead and rim edge.
Locate the tube valve and use your hand to push on the tire on the outside of the valve to help push the valve
further out through the rim.
Fill the tube with 50% air and then check the tire bead and rim edge again to see if the tube is protruding anywhere.
Once you confirm the tube is not protruding, you can fill the tire to your desired air pressure.
You are now ready to install the wheel back onto the bicycle according to the previous sections.
Chapter 9: Maintenance and Replacement
Your new Phantom X R was designed for ease of use and owner servicing. There are no tasks which require advanced
skills. Most maintenance and replacing of parts were designed to be accomplished by the typical bicycle rider. Please
read this section to learn how to keep your Phantom X R performing like new.
a) Keeping your bike clean
Your new Phantom X R is an outdoor friendly electric bicycle but should be kept clean and free from dirt. Dirt on and
around seals and drive train components can cause premature wear and dirt on paint and part finishes can cause
premature aging. If storing your bicycle outdoors under the elements, you must keep it covered with a high quality bicycle
cover to avoid rain, snow or dirt damaging your new bicycle.
To clean your bicycle, follow these instructions:
Your bicycle incorporates electrical components; it is advised when washing your bicycle you should first
cover the throttle and battery terminals. Use a plastic bag or a plastic wrap to cover the components. Place
the bag or wrap around the complete throttle assembly and use a rubber band or tape to secure. The
battery should be removed prior to cleaning and a plastic bag or wrap secured by tape can be used to cover
the battery terminal. If you are planning for a ride after washing, it is recommended the saddle also be
covered. The saddle has miniature holes where there is stitching and water can seep into these small holes.
To wash your bicycle you will need a small bucket of warm water with car soap, sponge, small brush, chain
lube and a few rags or towels.
Rinse your bicycle off with a light spray of water to remove any dirt on the surface. Using the sponge and
warm soapy water, wash the frame and frame components which include the forks, handlebar and seat
post. Start from the top of the bicycle working your way down.
Once the frame is washed, use the sponge to clean the motor, spokes, chain guard and rims.
The tires, pedals, crankset and chain will be the remaining items needing to be washed. Use the brush first
on the tires and then the pedals. Rinse the brush and then using the warm soapy water, clean the chain
ring, freewheel and finally the chain. If the chain and drive train are very dirty or greasy, a bicycle degreaser
should be utilized.
After washing, spray the bicycle down with fresh water.
Use the rags or towels to dry off the bicycle. Start by drying the frame first, followed by the components, the
wheels, tires and then the drive train.
Once the drive train is dry, use a chain lube to lubricate the chain.
b) Avoid scratching your bike
Your new Phantom X R is a high quality bicycle has been designed to withstand the elements by utilizing stainless
steel, anodized and painted aluminum alloys, brass plus galvanized or painted metals. Stainless steel and brass
are used in their natural forms and can withstand the elements with no additional protection required. The majority
of your bicycle however is fabricated from aluminum alloys which have either a painted finish or have been
anodized. Aluminum does not rust but can discolor and corrode over time. The frame has a 3 layer paint finish
which protects the aluminum and graphics. Components such as the handlebars, crank arms, chain guard, seat
post and more have been anodized through an electrolytic process which increases corrosion and wear resistance.
If the frame or components become scratched, these items could slightly corrode around the scratched area.
Depending on the care of your bicycle, a scratch could take month or years for corrosion to appear. To maintain
future value and years of beauty, it is best to be careful when folding and moving your bicycle not to scratch the
metal surfaces. If a surface is scratched, use clear nail polish or black nail polish to cover and seal the scratch.
