k) Maintenance schedule: As a common practice you should follow your maintenance schedule. You
should study it and allow it to become second nature to your riding.
Maintenance Schedule
Each Ride
Weekly
Monthly
6 Months
Yearly
Tire Pressure
X
Tire Condition
X
Visual Inspection
X
Brake Lever Pressure
X
Quick Releases
X
Handlebar Alignment
X
Saddle Alignment
X
Battery Pack Locked
X
Wheel Check
X
Inspect Frame Condition (include welds for fissures)
X
Clean and Lubricate Chain
X
Check Brake Pads
X
Lubricate Forks
X
Lubricate Brakes & Cables
X
Lubricate Folding Mechanism
X
Check All Bolts and Torque Settings
X
Clean Bicycle
X
Charge Battery
X
Check Wheel Spokes
X
Inspect Rim Condition
X
Inspect Saddle, Rails and Clamp
X
Grease Pedal Bearings
X
Check HUB Bearings
X
Check Headset Bearings
X
Check Bottom Bracket Bearings
X
Replace Brake Pads
X
Replace Brake Cables (depends on use)
X
Replace Tires (depends on use)
X
l) Torque specifications for common parts: Nuts and bolts for your bicycle are set to a standard torque
setting at the factory. Over time of use and shipping, nuts or bolts could become loose. Below is a chart of the torque
settings in Lb per Inch for the common parts of the Phantom X. They have also been converted to Lb per Foot and NM.
Torque Item
lb per In
lb per Ft
N M
Axle nut (front motor)
250 lb*in
20.8 lb*ft
28.25
Bottom bracket
420 lb*in
35 lb*ft
47.46
Brake lever clamps (at handlebar)
70 lb*in
5.8 lb*ft
7.91
Cassette/Freewheel
300 lb*in
25 lb*ft
33.9
Chainring bolts
80 lb*in
6.7 lb*ft
9.04
Crank bolt
350 lb*in
29.2 lb*ft
39.54
Crank bolt cap (if applicable)
100 lb*in
8.3 lb*ft
11.3
Derailleur bolt
80 lb*in
6.7 lb*ft
9.04
Disc brake caliper bolts (at frame)
80 lb*in
6.7 lb*ft
9.04
Disc rotor bolts
55 lb*in
4.6 lb*ft
6.21
Disc Brake Cable Arms (pinch bolt)
55 lb*in
4.6 lb*ft
6.21
Headset locknut
150 lb*in
12.5 lb*ft
16.95
Kickstand bolt
100 lb*in
8.3 lb*ft
11.3
Pedals
300 lb*in
25 lb*ft
33.9
Saddle rail clamp bolts (M6)
140 lb*in
11.7 lb*ft
15.82
Shifter (at handlebar)
20 lb*in
1.7 lb*ft
2.26
Stem adjustable bolts
150 lb*in
12.5 lb*ft
16.95
Stem clamp binder bolts (4 bolts)
60 lb*in
5 lb*ft
6.78
Stem steerer tube bolts
80 lb*in
6.7 lb*ft
9.04
Throttle
25 lb*in
2.1 lb*ft
2.825
V brake bolts (at frame)
80 lb*in
6.7 lb*ft
9.04
Quick Release (at half way tighten the lever with resistance)
