10
3.2 LED Display
Figure 11 Dimension of PMSWELD (Unit: mm)
Installation:
PM235 can be installed on a horizontal surface or vertically on a wall. Please see following instructions:
Figure 10 Installation of PM235 (Unit: mm)
Ensure clearance on both sides of PM235 unit
upon installation. A recommended clearance of
5cm on each side.
Figure 9 Dimension of PM235 (Unit: mm)
164
264
300
128
55
35
M4
7.97
150
90
23.62
