16
Congure the max charging current of PM235:
Figure 23 Dip Switch of PM200
6. OPERATION
6.1 Conguration on PM200
Battery type and capacity are congured via PM235 master power unit.
6.1.1 Battery Capacity and Battery Type
There is a dip switch for you to set battery capacity and battery type.
Dip switch denitions:
When choosing max charging
current, please take into
consideration the
consumption of the DC load
connected with the system.
Congure the battery type connected: Factory default setting:
Table 12 Dip Switch denition
Table 13 Battery Capacity setting by dip switch
Table 14 Battery Type setting by dip switch
Table 15 Factory default setting
1 2 3 4
ON
OFF
DIP
SWITCH
1 2 3 4
Charging Current Battery Type
DIP SWITCH 1 2 3 4
STATUS OFF OFF OFF OFF
LEAD ACID LITHIUM
DS1 DS2 AC CHARGE SOLAR CHARGE LITHIUM
ON ON 10A 20A 30A
ON OFF 15A 30A 30A
OFF ON 20A 30A 30A
OFF OFF 30A 30A 30A
DS3 DS4 BATTERY
TYPE
ABSORPTION FLOAT
OFF OFF AGM 14.4V 13.5V
OFF ON GEL 14.1V 13.5V
ON OFF LiFePO
4
14.2V 13.5V
ON ON WET 14.7V 13.7V
