5
1.1 Features
Smart battery charger 12V 35A (30A for charging current)
– Multi stage adaptive charging algorithm
Active Power Factor Correction (PFC) charging
Temperature compensation charging
Voltage compensation charging
Float charge for starter battery
Solar charge controller (PWM), 30A
14 built in fused outputs
Built in Voltage Sensing Relay
– 12V 60A Continuous
12V 100A Peak for 30mins
Battery low voltage protection
Built-in battery switch to isolate the battery when in storage
Built-in shunt for precise battery measurement
1 water pump control with up to 3 connections for water sensors
Dual control cooling fan
– Temperature Control
– Load Control
Spring terminal and screw terminal
RS-485 compatible
Figure 2 System Schematic
10A
K4
F5
L11+
10A
F6
L10+
LOAD
-
LOAD11 for PUMP
10A
F7
L9+
10A
F8
L8+
10A
F17
L14+
10A
F16
L13+
10A
F15
L12+
15A
F9
L7+
10A
F10
L6+
10A
F11
L5+
15A
F12
L4+
10A
F13
L3+
15A
F14
L2+
15A
F1
L1+
L13-
L12-
L11-
L10-
L9-
L8-
L7-
L6-
L5-
L4-
L3-
L2-
L14-
L1-
K3
D+Input
Remote Switch
Dip Switch
Load switch
35A
F4
F3
+
-
PWM
MCU
+
-
+
-
AC/DC
+
-
+
-
+
-
VCR
Battery switch
35A
K1
Solar In
AC In
Service
Battery
Starter
Battery
Step
Slave charger relay
K2
LOAD4 ~ 10 for
Class B Load
LOAD12 ~ 14 for
Class B Load
LOAD 2 ~ 3 for
Class C Load
LOAD1 for
Class D Load
