17
6.1.2 Select Battery Switch Local/Remote
This function offers a possibility for user to use a remote battery switch to power on/off the service battery output
DIP SWITCH DESCRIPTION
Local The switch on PM235 unit works
Remote The remote switch works and local one is disabled
6.2 Daily Maintenance
• Conrm the Battery Switch is switched on when you want to charge the battery with the AC grid.
• Check the nominal battery voltage is 12Vdc.
• Ensure the space (5cm each side) beside the PM235 unit for the good ventilation.
• When replacing and existing battery, please fully charge via AC grid to ensure SOC% is
accurately calibrated.
It is recommended to switch off the local Battery Switch on main panel of PM200 master power
unit or remote switch to cut off the consumption of the service battery.
Figure 24 Local/Remote Select Switch Table 16 Local/Remote Setting
Local
Remote
