3
CONTENTS
1. SYSTEM INTRODUCTION – PM200 ........................................................................................... 4
1.1 Features 5
1.2 LED display 6
1.3 Water tank probes 6
2. KEY FEATURES AND FUNCTIONS ............................................................................................... 6
2.1 Multiple inputs 6
2.2 Battery charger of stationery/service battery 6
2.3 Power supply mode 7
2.4 PWM solar charge controller 7
2.5 Voltage charging relay (VCR) 7
2.6 Categorised outputs 8
2.7 Battery low voltage protection 8
2.8 Manual battery switch 8
2.9 Silent mode 8
3. STRUCTURE AND INSTALLATION ............................................................................................... 9
3.1 PM235 Transformer Unit 9
3.2 LED display 10
3.3 Water tank probes 11
3.3.1 PMWS400 water tank probe 11
3.3.2 PMWS200 water tank probe 11
4. WIRING ....................................................................................................................................... 12
4.1 Material 12
4.2 System schematic 12
4.3 Preparation 13
4.4 Connection 13
5. DISPLAY ...................................................................................................................................... 14
5.1 PM200 master power unit 14
5.2 LED display 15
6. OPERATION ................................................................................................................................. 16
6.1 Conguration on PM200 16
6.1.1 Battery capacity and battery type 16
6.1.2 Select Battery Switch Local / Remote 17
6.2 Maintenance 17
7. TROUBLE SHOOTING .................................................................................................................. 18
7.1 LCD display on PM200 Unit 18
8. SPECIFICATION ........................................................................................................................... 19
8.1 PM200 Basic 19
