PROLiNK
®
PEN1201 Wireless-N 300Mbps Range Extender II
Page 4
1
WPS
To connect with Wi-Fi Client (e.g. mobile phone): Press and release
To connect with an existing Router’s Wi-Fi: Press and hold for 6
seconds
2
Wi-Fi Signal
To show the Wi-Fi Signal Strength Indicator
3
Status Indicator
To show the device status
4
Reset Button
Hold for 10 seconds and release to reset to factory setting
5
Power Switch
Top position: Turn OFF Extender/Bottom position: Turn ON Extender
6
Operation Mode
switch
Top position : Access Point (AP) Mode
Middle position : Repeater Mode
Bottom position : Router Mode
7
AC Power Input
To plug into switch socket outlet
8
WAN/LAN Port
For Router and AP Mode: this port is to be connected with Internet
source/Modem
For Repeater Mode: this port functions as a LAN port
9
LAN Port
Port to connect with a client’s (PC / Laptop) Ethernet port
