Parameter Descriptions Table (All levels are user-programmable. Some values are interdependent.
AVR Function Disable
AVR Function Enable
Default Setting Selections or
Selectable
Range
Default Setting Selections or
Selectable
Range
50. Buck Function
√
51. Boost Function
√
52. Sense Type Normal Normal Normal Normal
Generator Generator
53. Line Qualify Time Battery to Line
--------------------
30s 3s 30s 3s
10s 10s
30s 30s
54. Line High
When input voltage exceeds this level, unit tra
nsfers
to Battery Mode from either Buck Mode (when
AVR is
enabled) or Line mode.
Line to Battery
--------------------
130VAC
or
260VAC
120~152VAC
or
241~300VAC
152VAC
or
300VAC
120~152VAC
or
241~300VAC
55. Line Low
When input voltage is lower than this level, unit
transfers to Battery Mode from either Boost Mode
(when AVR is enabled) or Line Mode.
Line to Battery
--------------------
100VAC
or
200Vac
90~120VAC
or
176~240VAC
88VAC
or
176VAC
90~120VAC
or
176~240VAC
56. Boost Low
When input voltage
drops between Boost Back point
and Boost Low point, unit will transfer
to Boost Mode
only when AVR is enabled.
Normal to Boost
--------------------
[DISABLE] 102VAC
or
216VAC
96~120VAC
or
192~240Vac
57. Buck High
When input voltage increases between
Buck High
point and Buck Back point, unit will
transfer to Buck
Mode only when AVR is enabled.
Normal to Buck
--------------------
[DISABLE] 128VAC
or
264VAC
120~144VAC
or
241~288VAC
58. High Gap 5VAC
or
10VAC
3~7VAC
or
6~14VAC
5VAC
or
10VAC
3~7VAC
or
6~14VAC
59. Low Gap 5VAC
or
10VAC
3~7VAC
or
6~14VAC
5VAC
or
10VAC
3~7VAC
or
6~14VAC
* High Back
When input voltage drops below this level, unit
transfers back to Line Mode from Battery Mode.
Battery to Line
-------------------- ( Line High - High Gap ) ( Line High - High Gap )
* Low Back
When input voltage rises above this level, unit
transfers back to the Line Mode from Battery Mode.
Battery to Line
--------------------
( Line Low + Low Gap ) ( Line Low + Low Gap )
* Boost Back
When input voltage rises above this level, unit
transfers to Normal Mode.
Boost to Normal
-------------------- [DISABLE]
( Boost Low + Low Gap )
* Buck Back
When input voltage drops below this level, unit
transfers back to the Normal Mode.
Buck to Normal
-------------------- [DISABLE]
( Buck High - High Gap )
