PROLiNK PRO2000LD User Manual

31
6.3 Charger Mode Specifications
6.4 General Specification
Dimension, W*D*H (mm)
400*240*133
Net Weight (Kgs)
13kg
Operation Temperature Range -40°C ~ 80°C for 120Vac model;
-40°C ~ 70°C for 230/240Vac model
Storage Temperature Range
-50°C ~ 80°C
Relative humidity
5% ~ 95% non-condensing
Audible Noise
< 48dB
Cooling
Forced Air
EMI
Class A FCC/CISPR [EN50091-2: 1995]
Surge protection
IEEE/ANSI C.62.41 & 2KV, L-N
Appropriate battery type
AGM
Charging Current
2Amp/ 4Amp/ 6Amp/ 8Amp/10Amp adjustable
Max charger current limitation
10
8
Temperature
( °C
)
Charger
Current(A)
40
50
Charging Algorithm
3-Step
Charger voltage Setting @25 °C
Battery Type
Boost CC, CV
Float
24/48Vdc
24/48Vdc
AGM 28.2/56.4Vdc 27.0/ 54.0Vdc
Battery Temperature Control
Charging voltage is compensated according to battery temperature
-2.5mV /-3.0mV/ -3.5mV/ -4.0mV per cell per°C compensated coefficient
adjustable
Charger on when battery temperature between - 20 °C to 50 °C
