Page 23
Fig. 4: Cable leadthrough – rear row
he
Fig. 5: Cable leadthrough – front row
5.3 Installing Lamp Protective Tubes
ATTENTION!
Take particular care during this work to ensure that the extended wiper rod is not bent!
Assembly and Installation
3
2
1
1 Knob
2 Guide pin
3 Fixing bush
4 Clamping screw
5 Wiper rod
6 O-ring
Fig. 6: Components of the manual wiper on the
chamber cover and parts of the UV lamp
1 PG-11 screwed gland
2 Metal ring
3 Rubber seal
5
4
4 PG-7 screwed gland
5 Lock nut
7 Chamber cover
8 Lamp protective
tube
9 O-ring
10 Protective tube
retaining fixture
7
1
2
3
4
5
6
8910
