Number and scope of setting menus
is dependent on the device.
Access to setting menus can
be blocked with access code.
calibration Cl
zero p.: 4.00 mA
slope:
6.50 mA/ppm
Permanent display 1
Only with servomotor
Only with pumps
0.45 ppm
70 %
59 %
ppm
0.45
mea val.
fd. fwd.
reg. val.:
Only with limit value
relay, solenoid valve
relay or servomotor
Permanent display 2
only with control
(w = setpoint)
w:
1.00 ppm
Only with correction
variable pH
Only with 2 standard
signal outputs
Only with feed
forward control
Only with control
Only with standard
signal output
calibration pH
zero p.: 0.0 mV
slope 25 °C
59.16 mV/pH
measuring range
setting ?
Only with correction
variable pH
measuring value
setting ?
correcting value
setting ?
pumps
setting ?
relays
setting ?
limits
setting ?
servomotor
setting ?
control
setting ?
feed forward ctrl.
setting ?
signal output 1
mA setting ?
signal output 2
mA setting ?
general setting
information
8 Complete Operating Menu / Overview
All parameters of the controller can be set in the complete operating menu (access see previous page). The
following overview shows the settings which can be selected:
D1C2-Cl-017-GB
