ProMinent DULCOMETER D1C User Manual

2
1 Device Identification / Identity Code
D1C A
Please enter the identity code of your device here!
D1C A DULCOMETER
®
Controller Series D1C / Version A
Type of mounting
D Control panel installation 96 x 96 mm (IP 54)
W Wall mounting (IP 65)
Operating voltage
0 230 V 50/60 Hz
1 115 V 50/60 Hz
2 200 V 50/60 Hz (only with control panel installation)
3 100 V 50/60 Hz (only with control panel installation)
4 24 V AC/DC
Measured variable
C Chlorine (0-0.5/2/5/10/20/50/100 ppm)
Connection of measured variable
1 Terminal, standard signal 0/4-20 mA
Correction variable
0 None
1 pH for chlorine via standard signal 0/4-20 mA
Feed forward control
0 None
1 Flow as standard signal 0/4-20 mA
2 Flow as frequency 0-500 Hz
3 Flow as frequency 0-10 Hz
Control input
0 None
1 Pause
Signal output
0 None
1 Standard signal 0/4-20 mA measured value
2 Standard signal 0/4-20 mA control variable
3 Standard signal 0/4-20 mA correcting variable
42 standard signal 0/4-20 mA outputs, freely programmable
Power control
G Alarm and 2 limit value/timer relays
M Alarm and 2 solenoid valve relays
R Alarm relay and servomotor with feedback
Pump control
0 None
2 Two pumps
Control characteristic
0 None
1 Proportional control
2 PID control
Log output
0 None
Language
D German
E English
F French
I Italian
N Dutch
S Spanish
PPolish
ASwedish
B Portuguese
U Hungarian
G Czech
