27
Complete Operating Menu / Description
D1C2-Cl-028-GB
Access to all setting menus can be blocked with an access code !
general setting
information
ident-code: D1CA
software version
DxCxxxxxxxxxx
D1C-A1 FW-5.00
alarm relay
access c.:
=
=
operating menu:
active
5000
english
complete
pause normal
- active closed
- alarm off
- td: 0 min.
General setting
Possible values
Initial value Increment Lower value Upper value Remarks
Alarm relay active active
not active
Control input pause closed closed
open
Pause Pause Pause/Hold*
Pause
Control input pause active closed active closed Acts as N/O
active open Acts as N/C
Pause with alarm alarm off alarm off Alarm relay can be
alarm on triggered by pause contact.
td 0 min 1 min 0 min 60 min
Access code 5000 1 1 9999
Language as per identity code as per identity code
Operating menu complete reduced
complete
BA_DM_173_03_09_GB.p65 30.03.2009, 12:10 Uhr27
