15 Technical data
WARNING!
Risk of personal injuries
Please observe the ”Supplement for modified version“ at
the end of the chapter!
It replaces and supplements the technical data!
15.1 Performance data
Type Minimum pump capacity at maximum
back pressure
Maximum
stroke rate
Suction lift Permissible
priming pres‐
sure, suction
side
Connector
size
bar l/h ml/stroke Strokes/min m WS bar R"-DN
12017 PVT 12 17 3.8 73 7 1 3/4" - 10
12017 SST 12 17 3.8 73 7 1 3/4" - 10
12035 PVT 12 35 4.0 143 7 1 3/4" - 10
12035 SST 12 35 4.0 143 7 1 3/4" - 10
10050 PVT 10 50 4.0 205 7 1 3/4" - 10
10050 SST 10 50 4.0 205 7 1 3/4" - 10
10022 PVT 10 22 5.0 73 6 1 3/4" - 10
10022 SST 10 22 5.0 73 6 1 3/4" - 10
10044 PVT 10 44 5.1 143 6 1 3/4" - 10
10044 SST 10 44 5.1 143 6 1 3/4" - 10
07065 PVT 7 65 5.2 205 6 1 3/4" - 10
07065 SST 7 65 5.2 205 6 1 3/4" - 10
07042 PVT 7 42 9.5 73 3 1 1" - 15
07042 SST 7 42 9.5 73 3 1 1" - 15
04084 PVT 4 84 9.7 143 3 1 1" - 15
04084 SST 4 84 9.7 143 3 1 1" - 15
04120 PVT 4 120 9.7 205 3 1 1" - 15
04120 SST 4 120 9.7 205 3 1 1" - 15
All figures refer to water at 20 °C.
The suction lift applies to a filled suction line and filled liquid end - when
installed correctly.
Only with "M - modified" design:
S1Ba with 50 Hz operation
Technical data
59
