Pos. Type Quantity Article Order no.
001 A 1.000 Liquid end Sigma 1 - 50 SSTH 1036541
001 B 1.000 Liquid end Sigma 1 - 65 SSTH 1036542
001 C 1.000 Liquid end Sigma 1 - 120 SSTH 1036543
100 A 1.000 Hyg.dos. head, complete 96.0 x 42.0 LK80 1035627
100 B 1.000 Hyg. dos.h. complete 96.0 x 48.5 HC8 1035730
100 C 1.000 Hyg. dos.h. complete 122.0 x 67.0 HC 1035731
104 A, B 1.000 Hyg. connection set TCVC DN10 1035924
104 C 1.000 Hyg. connection set TCVC DN15 1035945
110 A 1.000 Hyg. dos. head welded 96.0 x 42.0 1035623
110 B 1.000 Hyg. dos. head welded 96.0 x 48.5 1035624
110 C 1.000 Hyg. dos. head welded 122 x 67 LK 1035625
121 A-C 2.000 Hyg. valve seal TCVC 1035921
122 A-C 2.000 Hyg. valve inner part TCVC with seal 1038124
122 A-C 2.000 Hyg. valve, interior, without seal TCVC 1038922
123 A, B 1.000 Hyg. valve top part TCVC DN10 1035919
123 C 1.000 Hyg. valve top part TCVC DN15 1035933
124 A, B 1.000 Hyg. valve bottom part TCVC DN10 1035920
124 A 1.000 Hyg. valve bottom part TCVC DN15 1035944
125 A- B 2.000 Hyg. clamp connection TRICLAMP TCVC 1035923
200 A 1.000 Diaphragm 70 x 32 -M6 PTFE 1010279
200 B 1.000 Diaphragm 70 x 37 -M6 PTFE 1010282
200 C 1.000 Diaphragm 77.0x 33.5 -M5 PTFE 1000250
201 A 1.000 Backplate 96.0x42.0 HC 80 PPE 1010288
201 B 1.000 Backplate 96.0x48.5 HC 80 PPE 1010289
201 C 1.000 Backplate 105x44 - 2 LK66 PPE 1025060
202 A, B 4.000 Cyl. screw DIN 912 M 5x 80 468080
202 C 6.000 Cyl. screw DIN 912 M 5x 80 468080
203 A, B 4.000 Spring washer formerly DIN 7980 462455
203 C 6.000 Spring washer formerly DIN 7980 462455
Exploded drawings Sigma/ 1
83
