Tab. 10: Scope of delivery with PVT material version
1 x diaphragm, 2 x valve balls, 1 x suction valve complete, 1 x discharge valve complete
1 x elastomer sealing set (EPDM)
2 x ball seat housings, 2 x ball seat discs, 4 x composite seals
1x seal washer (for bleed valve or relief valve)
Tab. 11: Scope of delivery with SST material version
1 x diaphragm, 2 x valve balls
2 x cover rings
4 x composite seals
1x seal washer (for bleed valve or relief valve)
Tab. 12: Spare parts kits PVT (liquid ends)
Liquid end Types 12017, 12035, 10050 Types 10022, 10044, 07065 Types 07042, 04084, 04120
FM 50 - DN 10 1046466 - -
FM 65 - DN 10 - 1046469 -
FM 120 - DN 15 - - 1046453
Tab. 13: Spare parts kits SST (liquid ends)
Liquid end Types 12017, 12035, 10050 Types 10022, 10044, 07065 Types 07042, 04084, 04120
FM 50 - DN 10 1046468 - -
FM 50 - DN 10 with 2 com‐
plete valves
1046467 - -
FM 65 - DN 10 - 1046471 -
FM 65 - DN 10 with 2 com‐
plete valves
- 1046470 -
FM 120 - DN 15 - - 1046465
FM 120 - DN 15 with 2 com‐
plete valves
- - 1046464
Material version Liquid end Suction / pressure
connector
Seals* / ball seat Balls Integrated bleed
valve or relief
valve
PVT PVDF PVDF PTFE / PVDF Ceramic PVDF / EPDM
SST Stainless steel
1.4404
Stainless steel
1.4581
PTFE / PVDF Stainless steel
1.4404
Stainless steel /
EPDM
* Metering diaphragm is PTFE-coated; seals are PTFE composite seals
PTFE: FDA No. 21 CFR §177.1550
PVDF: FDA No. 21 CFR §177.2510
Ordering information
Wetted materials – "Physiologically safety
with regard to wetted materials" design
Wear parts for Sigma/ 1
85
