1 Identity code
Sigma X Control type – Sigma/ 2 - S2Cb
Product range
S2Cb
Drive type
H Main power end, diaphragm
Type Output
_ _ _ _ Performance data at maximum back pressure and type: refer to nameplate on the pump
housing
Dosing head material
PV PVDF
SS Stainless steel
Seal material
T PTFE
F FDA-compliant FDA No. 21 CFR §177.1550 (PTFE)
G 1935/2004 (10/2011)
H Hygienic design
Displacement body
W Multi-layer safety diaphragm with optical rupture indicator
A Multi-layer safety diaphragm with rupture signalling by electrical signal
Dosing head version
0 without bleed valve, without valve springs
1 without bleed valve, with valve springs
2 with bleed valve, without valve springs
3 with bleed valve, with valve springs
4 with relief valve, FPM, without valve springs
5 with relief valve, FPM, with valve springs
6 with relief valve, EPDM, without valve springs
7 with relief valve, EPDM, with valve springs
8 with bleed valve, EPDM, without valve springs
9 with bleed valve, EPDM, with valve springs
H Hygienic pump head with tri-clamp connectors (max. 10 bar)
Hydraulic connector
0 Standard threaded connector (in line with the technical data)
1 Union nut and PVC insert
2 Union nut and PP insert
3 Union nut and PVDF insert
4 Union nut and SS insert
7 Union nut and PVDF hose sleeve
8 Union nut and SS hose sleeve
9 Union nut and SS welding sleeve
Identity code
6
