Data Value Unit
Minimum temperature -10 °C
Data Value Unit
Max. temperature long-term at max. oper‐
ating pressure
90 °C
Max. temperature for 15 min at max. 2 bar 120 °C
Minimum temperature -10 °C
16.5.3 Air humidity
Air humidity, max. 95% relative humidity, non-condensing.
16.5.4
Degree of protection and safety requirements
Protection against contact and moisture:
The pump is designed in compliance with IP65 / NEMA4X Indoor (IEC
60529, EN629).
INFORMATION!: A CAN plug or the sealing cap provided needs to be
attached to the CAN socket for the HMI to guarantee protection against
contact and moisture.
Degree of protection:
1 - Mains connection with protective earth conductor
16.6 Installation height
Data Value Unit
Maximum installation height*: 1000 m above
standard
zero
* with standard pumps: Fit at higher installation heights at your own risk.
with ATEX pumps: We urgently advise that you contact a specialist for
ATEX motors at higher installation heights!
16.7 Electrical connection
The electrical data does not relate to the motor, but the
pump, which is connected as a whole unit.
Use the motor data sheet in the appendix for the motor
electrical data.
Identity code specification "Electrical power supply" - "U": 100 - 230 V ±
10%, 240 V ± 6%, 50/60 Hz
SST liquid end
Air humidity
Degree of protection
Safety requirements
Electrical data for the S2Cb pump
Technical data
85
