Tabs for locking mechanism insert. This piece must be
removed to unlatch the carrier. To remove, squeeze the
tabs together and pull out. To reinsert, squeeze the tabs
together and replace in position. Do not discard the
locking mechanisms.
Push here when
returning or replacing
the carrier into an
empty drive bay.
Pull here to release the carrier handle latch.
Then pull the carrier straight out by the handle.
Place your free hand under the carrier.
Do not drop the disk carrier, even if it is empty.
Vess A6600/A6800 Disk carrier with HDD installed - front view
Vess A7600/A7800 rive carrier front view
Carrier release button
18
