ProSoft Technology MVI56-MCM User Manual

Reference MVI56-MCM ♦ ControlLogix Platform
Modbus Communication Module
ProSoft Technology, Inc. Page 117 of 159
July 24, 2008
Register Content Description
5064 Error Delay Counter
This parameter specifies the number of polls to
skip on the slave before trying to re-establish
communications. After the slave fails to respond,
the master will skip commands to be sent to the
slave the number of times entered in this
parameter.
5065 to 5069 Spare
8.5.4 Port 1 Commands
Register Content Description
5070 to 5777 Command #1
This set of registers contains the parameters for
the first command in the master command list. The
structure of this data area is as described in
Integrating the Sample Ladder Logic into an
Existing Project (page 142)
5078 to 5085 Command #2 Command #2 data set
- - -
5852 to 5859 Command #100 Command #100 data set
8.5.5 Port 2 Commands
Register Content Description
5870 to 5877 Command #1
This set of registers contains the parameters for
the first command in the master command list. The
structure of this data area is as described in
Integrating the Sample Ladder Logic into an
Existing Project (page 142)
5878 to 5885 Command #2 Command #2 data set
- - -
6662 to 6669 Command #100 Command #100 data set
8.5.6 Misc. Status
Register Content Description
6670 Program Scan Count
This value is incremented each time a complete
program cycle occurs in the module.
6671 to 6672 Product Code
These two registers contain the product code of
"MCM".
6673 to 6674 Product Version
These two registers contain the product version
for the current running software.
6675 to 6676 Operating System
These two registers contain the month and year
values for the program operating system.
6677 to 6678 Run Number
These two registers contain the run number value
for the currently running software.
6679
Port 1 Command List
Requests
This field contains the number of requests made
from this port to slave devices on the network.
6680
Port 1 Command List
Response
This field contains the number of slave response
messages received on the port.
