ProStar 1K - Page 14

11
3KB
3.2.3 Rack Mount Battery Pack
17
5
15
2U Battery Pack
17
5
15
3U Battery Pack
1. Smart slot
2. RS-232 port
3. Output receptacles
4. Ground terminal
5. External battery connector (only for
long-run models, short backup models are
option)
6. Emergency power off connector (option)
7. USB port
8. Input circuit breaker
9. AC Input socket
10. Maintenance bypass switch (option)
11. Cooling fan
12. AC Input terminal
13. AC Output terminal
14. AC Input/Output terminal
15. Battery pack output circuit breaker
16. Battery bank
17. Rack mount hole
18. Parallel operation port (option)
17
3
5
8
9
11
6
1
2
7
Schuko Type
17
3
5
8
9
11
6
1
2
7
Universal Type
17
3
5
8
9
11
6
1
2
7
IEC Type
4
4
4
