Prostat PRS-801B - Page 12

10
Number
Feature
Indication
Indicates battery life status.
MEASUREMENT
MODE
Toggles between Continuous, Auto, Manual and Auto-
Manual modes.
Toggles between Record when measuring, and Recall
when accessing the memory.
MEMORY INDICATOR
Displayed when in Recall. FULL is displayed when the
memory is full.
EP
MEMORY LOCATION
Indicated the number of Seconds for the Electrification
Period when in Record. Indicates the memory location
when in Recall.
MIN, MAX, AVG
Displays the Minimum value, Maximum value, and
Average of the measurements in Memory.
SECONDS INDICATION
Displayed while in Record.
Indicated the meter is ready for operation.
Indicates a stable measurement was attained.
OHMIC RANGE
Indicates the ohmic range of a measurement while in
Record. Active only when Ω display format is selected.
APPLIED TEST
VOLTAGE
Displays which voltage being applied during a
measurement.
Decimal point.
Digital numerical value.
Table 3. Display Features
12
11
10
9
7
6
5
4
2
1
8
3
