25
Backup data feature
Connect 2.0 allows you to create a backup file of the data you upload from your PRS-801B:
1. In Connect 2.0, under Backup File, you will see a default path on your PC.
NOTE
The default file name will use the current date and will be saved as a CSV file (comma-separated
values). To change the name of the file, locate the file in Windows and change its name.
2. You can give this set of data a description.
3. All data uploaded on the same date will append to the same single CSV file.
07 MAINTENANCE AND USER ADJUSTMENT
Maintenance
The resistance meter is factory calibrated and other than battery replacement and external cleaning,
general user maintenance is not required. The case has been sealed and BREAKING THE SEALS WILL
VOID THE WARRANTY.
For complete service, disassembly, repair, and calibration information, contact Prostat or an
Authorized Calibration Lab for assistance.
Clean the meter case with a dry, soft, non-scratching cloth
Do not use abrasives, solvents, or alcohol. These may damage the membrane switch.
Carefully wipe the case and display until dust and dirt are removed
CAUTION
In rare cases cleaning the resistance meter case with a slightly dampened cloth may be required.
Should this be required, use a very weak solution of liquid soap and water. The cloth should be
barely damp. DO NOT allow cleaning solution to enter the unit through its openings. Should the
unit become damaged through the use of cleaning solutions, the warranty will be voided.
