93-508-08 Issue 2 Page 12 of 22 Copyright Protec Fire Detection PLC
PRINT ANALOGUE VALUES ON LOOP XX
BETWEEN ADDRESSES XXX AND XXX
6.1.1 PRINTING ANALOGUE VALUES
Find the ‘ANALOGUE VALUES’ option from the ‘Printer Menu’ option using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
Choose the loop from which the device values are to be printed using ‘NEXT/PREVIOUS’. Press ‘ACCEPT’ to
move the cursor to the start address value. Use ‘NEXT/PREVIOUS’ to alter the address start value then press
‘ACCEPT’ to move on to the address finish value and set this in the same way. Press ‘ACCEPT’ to activate the
printout. The average value for each address is also printed for comparison. The average value is a long-term
function, which is updated every 8 hours.
Example: -
Note: - The analogue values will not be printed if the end address is not set above the start address.
To cancel printing, see section 6.1.8 CANCELING THE PRINTOUT. See Appendix A to interpret the values.
Press the ‘MENU’ button to return to the ‘Printer Menus’.
***************************************
LOOP 1 ADDRESS DATA
10:45:48 16/01/00
ADDR. DEVICE TYPE CHANNEL 1 CHANNEL 2
VAL AVE. VAL AVE.
01 ZAI 85
02 ZAI 85
06 OPTHEAT 55 58 118 115
11 ION 104 104
****************************************
