93-508-08 Issue 2 Page 15 of 22 Copyright Protec Fire Detection PLC
6.1.5 PRINTING DEVICE DATA
Find the ‘DEVICE DATA’ option from the ‘Printer Menus’ option using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
Press ‘ACCEPT’ and the panel will print out device data for all loops, and exit back to the ‘Printer Menus’.
Device Data example printout: -
To cancel printing, see section 6.1.8 CANCELING THE PRINTOUT.
****************************************
LOOP 1 ALLOCATION DATA 3 DEVICES
09:57:48 16/01/00
ADD SERNUM ZN IG OG MODE TYPE VR GG DG
01 765640 09 01 01 FIX MCP 00 00 00
02 0001CC 01 04 01 GEN OPTICAL 00 00 00
03 B0F0DF 03 05 01 GEN ION 00 00 00
