LP1 ADD 01 02 03 04 05 06 07 08
Ch1 T00 55 50 51 55 50 49 57 56
LOOP XX ADDRESS XX devtype MODE XXXXXXX
Text Associated With Address
6.3 VIEWING ANALOGUE VALUES
Find the ‘READ ANALOGUE DATA?’ option from the ‘Advanced Options’ menu using ‘NEXT’ and
‘PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
The analogue value for each address on the top line is displayed directly below it. The values are updated every
3 seconds. As each value is updated a ‘-‘ is toggled on and off in front of the address. See Appendix A to
interpret the values.
1) Use ‘NEXT/PREVIOUS’ to select the loop then press ‘ACCEPT’ to move the cursor to the ADD position.
2) Use ‘NEXT/PREVIOUS’ to view the previous/next block of eight addresses on the loop of interest.
Press ‘ACCEPT’ to move the cursor to the channel position.
3) Use ‘NEXT/PREVIOUS’ to toggle between channel 1 and 2. Press ‘ACCEPT’ to move the cursor to Tnn.
4) Use ‘NEXT/PREVIOUS’ to select a different time average. Values above T04 are for diagnostic purposes.
Pressing ‘ACCEPT’ moves the cursor back to the loop number.
Press ‘MENU’ to return to the ‘Advanced Options’ menu.
Note: On a networked system, only the panel’s own loop devices analogue values can be viewed (not global).
6.4 VIEWING ADDRESS TEXT
The pre-programmed text associated with each address can be viewed.
Find the ‘VIEW TEXT?’ option from the ‘Advanced Options’ menu using ‘NEXT/PREVIOUS’ buttons.
Press ‘ACCEPT’. The LCD displays: -
The text displayed along the bottom line of the display is that which corresponds to the loop number and
address shown on the top line.
1) Use ‘NEXT/PREVIOUS’ to select the loop then press ‘ACCEPT’ to move to the address position.
2) Use ‘NEXT/PREVIOUS’ to select the address then press ‘ACCEPT’ to move back to the loop position.
Press ‘MENU’ to return to the ‘Advanced Options’ menu.
Note: On a networked system, only the panel’s own loop devices text can be viewed (not global).
